Ion Exchange (IEX) media

IEX SepFast 6HF

£66.03£1,350.80 ex. VAT

Description

Q SepFast 6HF, DEAE SepFast 6HF, SP SepFast 6HF and CM SepFast 6HF are a group of strong anion exchange, weak anion exchange, strong cation exchange and weak cation exchange media, respectively.

The above ion-exchange chromatography (IEX) media is designed for the general purification of biological molecules in which impure components can be chromatographically separated from target molecules at a less demanding process.

The base matrix is made of highly cross-linked 6% agarose. It is very stable to most of the chemical conditions experienced in the bioprocessing industry. The IEX SepFast 6HF could be a good alternative to the IEX Sepharose 6FF with the benefit of reduced cost. We provide the regulatory support files of individual resins for those cGMP applications.

The core advantages to large-scale biomanufacturings are:

  • Good dynamic binding capacity
  • Good pressure / flow property
  • Low cost

Pre-packed columns for screening and process development use are available at following sizes: 1 ml, 5 ml, 3.8 ml (7x100mm ID x BH), 9.5 ml (11x100mm ID x BH), 20 ml (16x100mm ID x BH), 53 ml (26x100mm ID x BH). All these columns have connections fully compatible to Akta systems. Column hardware has 6 bar (0.6 MPa) pressure rating. See Column Instruction for details of HiSep and Optio column hardware.

Pre-packed columns for pilot to production scale use with column diameter ranging from 5cm to 45cm are available on request. For bulk loose media, please contact us.

The range of IEX SepFast 6HF media is developed and supported for production scale chromatography use. Regulatory Support File (RSF) is available to assist process validation and submissions to regulatory authorities.

Further information about IEX SepFast 6HF

Characteristics of IEX SepFast 6HF

Matrix

Highly cross-linked 6% agarose

Functional Group

Quaternary ammonium strong anion (Q SepFast 6HF)

Diethylaminoethyl weak anion (DEAE SepFast 6HF)

Sulfopropyl strong cation (SP SepFast 6HF)

Carboxymethyl weak cation (CM SepFast 6HF)

Total Ionic Capacity

0.1-0.2 mmol/ml (Q SepFast 6HF)

0.08-0.13 mmol/ml (DEAE SepFast 6HF)

0.15-0.25 mmol/ml (SP SepFast 6HF)

0.08-0.13 mmol/ml (CM SepFast 6HF)

Dynamic Binding Capacity*

>100 mg BSA / ml (Q SepFast 6HF)

>100 mg BSA / ml (DEAE SepFast 6HF)

>110 mg lysozyme / ml (SP SepFast 6HF)

>110 mg lysozyme / ml (CM SepFast 6HF)

*Test condition: 10 mM buffer pH 7.5, 5 mg/ml protein to load, residence time 5 min, 50% breakthrough

Particle Size

50 – 150 μm

Pressure-Flow Property**

>500 cm/hr at 3 bar

**Measured in a 32 mm ID column at a bed height of 15 cm using water at room temperature.

Operational Pressure

Up to 3 bar

pH Stability

2-14 (short term) and 3-12 (long term) (Q SepFast 6HF and DEAE SepFast 6HF)

2-14 (short term) and 4-12 (long term) (SP SepFast 6HF and CM SepFast 6HF)

Working Temperature

+4°C – +30°C

Chemical Stability

All commonly used buffers; 1 M acetic acid, 1 M NaOH, 6M guanidine hydrochloride, 8 M urea, 30% isopropanol, 70% ethanol

Avoid

Oxidizing agents, anionic detergents (Q SepFast 6HF and DEAE SepFast 6HF)

Oxidizing agents, cationic detergents (SP SepFast 6HF and CM SepFast 6HF)

Storage

20% ethanol (Q SepFast 6HF)

20% ethanol (DEAE SepFast 6HF)

20% ethanol + 0.2M sodium acetate (SP SepFast 6HF)

20% ethanol (CM SepFast 6HF)
